Teensy 3.5 Development Board

Teensy 3.5 Development Board
Teensy 3.5 Development Board
Teensy 3.5 Development Board
Teensy 3.5 Development Board
Teensy 3.5 Development Board
Teensy 3.5 Development Board
Teensy 3.5 Development Board
Based on 0 reviews. - Write a review
₹2,249.00
Ex GST: ₹1,905.93
Price in reward points: 21
  • Stock: In Stock
  • Reward Points: 21
  • Model: 7765
  • SKU: SAT1927
  • Location: India
Generic Generic
Add to Cart
Buy Now
Add to Wish List Compare this Product
Free Returns
Full refund on Damage
Secure Checkout
We follow highest security standards
Secure Shopping
Best security features
Technical Support
Ask us if you need help
The Teensy USB Development Board is a complete USB-based microcontroller development system. Version 3.5 features a 32 bit 120 MHz ARM Cortex-M4 processor with floating point unit. All digital pins are 5 volts tolerant. All Teensy boards are shipped assembled and fully tested.
The Teensy is a breadboard-friendly development board with loads of features in a, well, teensy package. Each Teensy 3.5 comes pre-flashed with a bootloader so you can program it using the onboard USB connection: no external programmer needed! You can program for the Teensy in your favorite program editor using C or you can install the Teensyduino add-on for the Arduino IDE and write Arduino sketches for it!
The processor on the Teensy also has access to the USB and can emulate any kind of USB device you need it to be, making it great for USB-MIDI and other HID projects. The 32-bit, 120MHz processor brings a few other features to the table as well, such as multiple channels of Direct Memory Access, several high-resolution ADCs, and even an I2S digital audio interface! There are also four separate interval timers, plus a delay timer! Oh yeah, and all digital pins have interrupt capability and are 5V tolerant.
All of this functionality is jammed into a 62.3mm x 18.0mm board with all solder points on a 0.1″ grid so you can slap it on a breadboard and get to work! The Teensy 3.5 is larger, faster and capable of more projects, especially with its onboard micro SD card port. An upgraded ARM Cortex MCU (120MHz from 72MHz), more memory (512K from 256K), as well as more RAM, EEPROM and accessible pins make up the key new features of this “teensy” board. The Teensy 3.5 is slightly scaled down from the Teensy 3.6 but is offered at a cheaper price point, comparatively.

Note: This does not come with a USB cable; please check our website for an appropriate one.

Features:

  • 120MHz ARM Cortex-M4 with Floating Point Unit
  • 512K Flash, 192K RAM, 4K EEPROM
  • Microcontroller Chip MK64FX512VMD12
  • 1 CAN Bus Port
  • 16 General Purpose DMA Channels
  • 5V Tolerance on All Digital I/O Pins
  • 62 I/O Pins (42 breadboards friendly)
  • 25 Analog Inputs to 2 ADC with 13-bit resolution
  • 2 Analog Outputs (DAC) with 12-bit resolution
  • 20 PWM Outputs (Teensy 3.6 has 22 PWM)
  • USB Full Speed (12Mbit/sec) Port
  • Ethernet mac, capable of full 100Mbit/sec speed
  • Native (4-bit SDIO) micro SD card port
  • I2S Audio Port, 4-Channel Digital Audio Input & Output
  • 14 Hardware Timers
  • Cryptographic Acceleration Unit
  • Random Number Generator
  • CRC Computation Unit
  • 6 Serial Ports (2 with FIFO and Fast Baud Rates)
  • 3 SPI Ports (1 with FIFO)
  • 3 I2C Ports
  • Real-Time Clock
  • 62.3mm x 18.0mm x 4.2mm (2.5in x 0.7in x 0.2in)


Package Includes:

1 x Teensy 3.5 Development Board
1 x Pinout Drawing Card

6 Months Warranty

This item is covered with a supplier warranty of 6 months from the time of delivery against manufacturing defects only. This is a quality product from the original manufacturer. Only manufacturing defects are covered under this warranty. Reimbursement or replacement will be done against manufacturing defects.

What voids the warranty:

If the product is subject to misuse, tampering, static discharge, accident, water or fire damage, use of chemicals & soldered or altered in any way.
