Mamba F4 pro V2 flight controller

Mamba F4 pro V2 flight controller
Mamba F4 pro V2 flight controller
Mamba F4 pro V2 flight controller
Mamba F4 pro V2 flight controller
Mamba F4 pro V2 flight controller
Mamba F4 pro V2 flight controller
Mamba F4 pro V2 flight controller
Based on 0 reviews. - Write a review
₹2,892.00
Ex GST: ₹2,450.85
  • Stock: In Stock
  • Model: 8073
  • SKU: SAT2235
  • Location: India
Generic Generic
Add to Cart
Buy Now
Add to Wish List Compare this Product
Free Returns
Full refund on Damage
Secure Checkout
We follow highest security standards
Secure Shopping
Best security features
Technical Support
Ask us if you need help

Stack Mamba F4 pro+V2 flight controller with your desired compatible ESC to build your F4 V2 pro flight controller. This F4 Pro + V2 has a Size of  36 x 36mm with Mounting Holes at the pitch of 30.5×30.5mm and its Net Weight is 13g. This Omnibus F4 Flight Controller equipped with Processor: STM32F405


Features:

  • Gyroscope: MPU6000 (reserved external gyroscope interface)
  • Firmware: BetaFlihgt 3.2.0 OMNIBUSF4SD
  • Support Receiver: PPM, SBUS, IBUS, DSM2/DSMX Receiver (UART1)
  • Integrated with OSD, support BF Ground Station adjust OSD
  • Adjust the PID by OSD by remote control
  • Support Dshot Protocol
  • Support SmartAudio, adjust the VTX by OSD (UART3)
  • MicroSD card BlackBox


Specification:

  • Input voltage: 2 – 6s LiPo support
  • BEC Output: 5V 3A
  • Baro (BMP280)
  • 5.8G 40CH 25/200/600/800mW FPV Transmitter
  • Frequency: 5362 – 5945MHz
  • Video Format: NTSC / PAL
  • Transmit power: 25 / 200 / 600 / 800mW switchable
  • Working voltage: DC 7 – 24V
  • Output voltage: 5V / 450mA
  • Operating Current:
  •    240mA @ 25mW
  •    340mA @ 200mW
  •    520mA @ 600mW
  •    600mA @ 800mW
  • Transmission Distance:
  •    200m @ 25mW
  •    2KM @ 200mW
  •    4KM @ 600mW
  •    6KM @ 800mW
  • Remote Software protocol: SmartAudio V2.0
  • Audio Bandwidth: 6.5MHz
  • Video Bandwidth: 18MHz
  • Channel: 40CH
  • Range: up to 4km omnidirectional RHCP antenna
  • Connector: MMCX
  • Board Dimensions (L x W x H) mm: 30.5×30.5 x 9
  • Weight (g): 15


Package Includes:

1 x Mamba F4 Pro+ V2 Flight Controller

1 x Connecting Wires
