The WiFi module ESP-1 is manufactured by using a high-performance chip ESP8285. This small chip is encapsulated an enhanced Tensilica’s L106  Diamond series 32-bit kernel CPU with an SRAM. Thus, ESP8285 has the complete function of Wi-Fi function; it not only can be applied independent but can be used as a slave working with other host CPU. When ESP8285 is applied as a slave, it can start from the onboard Flash.

The built-in high-speed buffer is not only benefiting improve the system performance but optimizing the store system. In addition, ESP8285 can be used as a Wi-Fi adapter by SPI/SDIO or I2C/UART interface, when it is applied to other MCU design.

Features:

  • Ultra-small size.
  • Support serial to WiFi
  • Wireless transparent transmission.
  • Long-distance transmission with ultra-low power.
  • Support outboard antenna.
  • Bearing high temperature to 125 ºC, compared to the 85ºC for ESP8266.
  • Module size:24.5mm x 14mm.
  • Derived from ESP8266, ESP8285 has a flash memory of 1MB
  • Totally compatible with ESP8266
  • WiFi support 802.11 b/g/n/e/i
  • High temperature resistant, working temperature: -40℃-125℃
  • SOC characteristics:
  • Built-in Tensilica L106 ultra-low power consumption 32-bit CPU,  the main frequency can be 80MHz and
  • 160MHz,  also support RTOS;
  • Built-in TCP/IP protocol stack;
  • Built-in 1 channel 10-bit high precision ADC;
  • The outside interfaces have HSPI, UART, I2C, I2S, IR Remote Control, PWM, GPIO;
  • The deep-sleep current is about 10uA, and the cut-off current is smaller than 5uA;
  • Can be wake-up within 2 ms, and connect to transmit data package;
  • the consumer power is smaller than 1.0mW (DTIM3) when at standby status;
  • built-in 1M byte for SPI Flash.

Wi-Fi characteristics:

Support 802.11 b/g/n/e/i

Support three modes: Station, SoftAP, and SoftAP+STA;

Support Wi-Fi Direct(P2P);

Support hardware acceleration for CCMP (CBC-MAC, computation mode), TKIP (MIC, RC4),

API(SMS4), WEP(RC4), CRC;

P2P find, P2P GO mode/GC mode and P2P power management;

WPA/PA2 PSK and WPS;

Support 802.11 i  security: pre-certification and TSN;

Support 802.11n (2.4 GHz);

802.1h/RFC1042 frame encapsulation;

Support seamless roam;

Support AT remote updation and cloud OTA update;

Support SmartConfig function for Android and iOS device SmartConfig.

Application:

Serial Transparent transmission;

WiFi probe;

Smart power plug/Smart LED light;

Mesh networks;

Sensor networks;

Wearable electronics;

Security ID label;

Wireless location recognition;

Wireless location system beacon;

Industrial wireless control.

Package Includes:

1 x DOIT Mini Ultra-Small size ESP-M3 Serial Wireless WiFi Transmission Module.

1 x Header Pins.
